前面介绍了java web三要素中filter的使用指南与常见的易错事项,接下来我们来看一下Servlet的使用姿势,本篇主要带来在SpringBoot环境下,注册自定义的Servelt的四种姿势
@WebServlet ServletRegistrationBean ServletContext
首先我们需要搭建一个web工程,以方便后续的servelt注册的实例演示,可以通过spring boot官网创建工程,也可以建立一个maven工程,在pom.xml中如下配置
<parent> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-parent</artifactId> <version>2.2.1.RELEASE</version> <relativePath/> <!-- lookup parent from repository --> </parent> <properties> <project.build.sourceEncoding>UTF-8</project.build.sourceEncoding> <project.reporting.outputEncoding>UTF-8</project.reporting.outputEncoding> <java.version>1.8</java.version> </properties> <dependencies> <dependency> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-web</artifactId> </dependency> </dependencies> <build> <pluginManagement> <plugins> <plugin> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-maven-plugin</artifactId> </plugin> </plugins> </pluginManagement> </build> <repositories> <repository> <id>spring-snapshots</id> <name>Spring Snapshots</name> <url>https://repo.spring.io/libs-snapshot-local</url> <snapshots> <enabled>true</enabled> </snapshots> </repository> <repository> <id>spring-milestones</id> <name>Spring Milestones</name> <url>https://repo.spring.io/libs-milestone-local</url> <snapshots> <enabled>false</enabled> </snapshots> </repository> <repository> <id>spring-releases</id> <name>Spring Releases</name> <url>https://repo.spring.io/libs-release-local</url> <snapshots> <enabled>false</enabled> </snapshots> </repository> </repositories>
为了紧跟SpringBoot的最新版本,从本篇文章开始,博文对应的示例工程中SpringBoot版本升级到 2.2.1.RELEASE
自定义一个Servlet比较简单,一般常见的操作是继承 HttpServlet
,然后覆盖 doGet
, doPost
等方法即可;然而重点是我们自定义的这些Servlet如何才能被SpringBoot识别并使用才是关键,下面介绍四种注册方式
在自定义的servlet上添加Servlet3+的注解 @WebServlet
,来声明这个类是一个Servlet
和Fitler的注册方式一样,使用这个注解,需要配合Spring Boot的 @ServletComponentScan
,否则单纯的添加上面的注解并不会生效
/** * 使用注解的方式来定义并注册一个自定义Servlet * Created by @author yihui in 19:08 19/11/21. */ @WebServlet(urlPatterns = "/annotation") public class AnnotationServlet extends HttpServlet { @Override protected void doGet(HttpServletRequest req, HttpServletResponse resp) throws ServletException, IOException { String name = req.getParameter("name"); PrintWriter writer = resp.getWriter(); writer.write("[AnnotationServlet] welcome " + name); writer.flush(); writer.close(); } }
上面是一个简单的测试Servlet,接收请求参数 name
, 并返回 welcome xxx
;为了让上面的的注解生效,需要设置下启动类
@ServletComponentScan @SpringBootApplication public class Application { public static void main(String[] args) { SpringApplication.run(Application.class); } }
然后启动测试,输出结果如:
➜ ~ curl http://localhost:8080/annotation/?name/=yihuihui # 输出结果 [AnnotationServlet] welcome yihuihui%
在Filter的注册中,我们知道有一种方式是定义一个Spring的Bean FilterRegistrationBean
来包装我们的自定义Filter,从而让Spring容器来管理我们的过滤器;同样的在Servlet中,也有类似的包装bean: ServletRegistrationBean
自定义的bean如下,注意类上没有任何注解
/** * Created by @author yihui in 19:17 19/11/21. */ public class RegisterBeanServlet extends HttpServlet { @Override protected void doGet(HttpServletRequest req, HttpServletResponse resp) throws ServletException, IOException { String name = req.getParameter("name"); PrintWriter writer = resp.getWriter(); writer.write("[RegisterBeanServlet] welcome " + name); writer.flush(); writer.close(); } }
接下来我们需要定义一个 ServletRegistrationBean
,让它持有 RegisterBeanServlet
的实例
@Bean public ServletRegistrationBean servletBean() { ServletRegistrationBean registrationBean = new ServletRegistrationBean(); registrationBean.addUrlMappings("/register"); registrationBean.setServlet(new RegisterBeanServlet()); return registrationBean; }
测试请求输出如下:
➜ ~ curl 'http://localhost:8080/register?name=yihuihui' # 输出结果 [RegisterBeanServlet] welcome yihuihui%
这种姿势,在实际的Servlet注册中,其实用得并不太多,主要思路是在ServletContext初始化后,借助 javax.servlet.ServletContext#addServlet(java.lang.String, java.lang.Class<? extends javax.servlet.Servlet>)
方法来主动添加一个Servlet
所以我们需要找一个合适的时机,获取 ServletContext
实例,并注册Servlet,在SpringBoot生态下,可以借助 ServletContextInitializer
ServletContextInitializer主要被RegistrationBean实现用于往ServletContext容器中注册Servlet,Filter或者EventListener。这些ServletContextInitializer的设计目的主要是用于这些实例被Spring IoC容器管理
/** * Created by @author yihui in 19:49 19/11/21. */ public class ContextServlet extends HttpServlet { @Override protected void doGet(HttpServletRequest req, HttpServletResponse resp) throws ServletException, IOException { String name = req.getParameter("name"); PrintWriter writer = resp.getWriter(); writer.write("[ContextServlet] welcome " + name); writer.flush(); writer.close(); } } /** * Created by @author yihui in 19:50 19/11/21. */ @Component public class SelfServletConfig implements ServletContextInitializer { @Override public void onStartup(ServletContext servletContext) throws ServletException { ServletRegistration initServlet = servletContext.addServlet("contextServlet", ContextServlet.class); initServlet.addMapping("/context"); } }
测试结果如下
➜ ~ curl 'http://localhost:8080/context?name=yihuihui' # 输出结果 [ContextServlet] welcome yihuihui%
接下来的这种注册方式,并不优雅,但是也可以实现Servlet的注册目的,但是有坑,请各位大佬谨慎使用
看过我的前一篇博文 191016-SpringBoot系列教程web篇之过滤器Filter使用指南 的同学,可能会有一点映象,可以在Filter上直接添加 @Component
注解,Spring容器扫描bean时,会查找所有实现Filter的子类,并主动将它包装到 FilterRegistrationBean
,实现注册的目的
我们的Servlet是否也可以这样呢?接下来我们实测一下
@Component public class BeanServlet1 extends HttpServlet { @Override protected void doGet(HttpServletRequest req, HttpServletResponse resp) throws ServletException, IOException { String name = req.getParameter("name"); PrintWriter writer = resp.getWriter(); writer.write("[BeanServlet1] welcome " + name); writer.flush(); writer.close(); } }
现在问题来了,上面这个Servlet没有定义urlMapping规则,怎么请求呢?
为了确定上面的Servlet被注册了,借着前面Filter的源码分析的关键链路,我们找到了实际注册的地方 ServletContextInitializerBeans#addAsRegistrationBean
// org.springframework.boot.web.servlet.ServletContextInitializerBeans#addAsRegistrationBean(org.springframework.beans.factory.ListableBeanFactory, java.lang.Class<T>, java.lang.Class<B>, org.springframework.boot.web.servlet.ServletContextInitializerBeans.RegistrationBeanAdapter<T>) @Override public RegistrationBean createRegistrationBean(String name, Servlet source, int totalNumberOfSourceBeans) { String url = (totalNumberOfSourceBeans != 1) ? "/" + name + "/" : "/"; if (name.equals(DISPATCHER_SERVLET_NAME)) { url = "/"; // always map the main dispatcherServlet to "/" } ServletRegistrationBean<Servlet> bean = new ServletRegistrationBean<>(source, url); bean.setName(name); bean.setMultipartConfig(this.multipartConfig); return bean; }
从上面的源码上可以看到,这个Servlet的url要么是 /
, 要么是 /beanName/
接下来进行实测,全是404
➜ ~ curl 'http://localhost:8080/?name=yihuihui' {"timestamp":"2019-11-22T00:52:00.448+0000","status":404,"error":"Not Found","message":"No message available","path":"/"}% ➜ ~ curl 'http://localhost:8080/beanServlet1?name=yihuihui' {"timestamp":"2019-11-22T00:52:07.962+0000","status":404,"error":"Not Found","message":"No message available","path":"/beanServlet1"}% ➜ ~ curl 'http://localhost:8080/beanServlet1/?name=yihuihui' {"timestamp":"2019-11-22T00:52:11.202+0000","status":404,"error":"Not Found","message":"No message available","path":"/beanServlet1/"}%
然后再定义一个Servlet时
@Component public class BeanServlet2 extends HttpServlet { @Override protected void doGet(HttpServletRequest req, HttpServletResponse resp) throws ServletException, IOException { String name = req.getParameter("name"); PrintWriter writer = resp.getWriter(); writer.write("[BeanServlet2] welcome " + name); writer.flush(); writer.close(); } }
再次测试
➜ ~ curl 'http://localhost:8080/beanServlet1?name=yihuihui' {"timestamp":"2019-11-22T00:54:12.692+0000","status":404,"error":"Not Found","message":"No message available","path":"/beanServlet1"}% ➜ ~ curl 'http://localhost:8080/beanServlet1/?name=yihuihui' [BeanServlet1] welcome yihuihui% ➜ ~ curl 'http://localhost:8080/beanServlet2/?name=yihuihui' [BeanServlet2] welcome yihuihui%
从实际的测试结果可以看出,使用这种定义方式时,这个servlet相应的url为 beanName + '/'
然后问题来了,只定义一个Servlet的时候,根据前面的源码分析,这个Servlet应该会相应 http://localhost:8080/
的请求,然而测试的时候为啥是404?
这个问题也好解答,主要就是Servlet的优先级问题,上面这种方式的Servlet的相应优先级低于Spring Web的Servelt优先级,相同的url请求先分配给Spring的Servlet了,为了验证这个也简单,两步
BeanServlet2
类上的注解 @Component
BeanServlet1
的类上,添加注解 @Order(-10000)
然后再次启动测试,输出如下
➜ ~ curl 'http://localhost:8080/?name=yihuihui' [BeanServlet1] welcome yihuihui% ➜ ~ curl 'http://localhost:8080?name=yihuihui' [BeanServlet1] welcome yihuihui%
本文主要介绍了四种Servlet的注册方式,至于Servlet的使用指南则静待下篇
常见的两种注册case:
@WebServlet
注解放在Servlet类上,然后启动类上添加 @ServletComponentScan
,确保Serlvet3+的注解可以被Spring识别 ServletRegistrationBean
不常见的两种注册case:
ServletContextInitializer
,通过 ServletContext.addServlet
来注册自定义Servlet beanName + '/'
尽信书则不如,以上内容,纯属一家之言,因个人能力有限,难免有疏漏和错误之处,如发现bug或者有更好的建议,欢迎批评指正,不吝感激
